Battery-free BLE sensor beacon is powered over 120 feet
The platform uses Powercast’s RF-to-DC power harvesting technology to power InPlay’s active Bluetooth sensor IN100, the first of InPlay’s NanoBeacon SoC family. The IN100 can be attached to nearly anything for real-time location monitoring, and paired with sensors to monitor conditions such as light, humidity and temperature.
Powercast says its far-field wireless technology has now powered the NanoBeacon IN100 from 120 feet away from the commercially-available PowerSpot transmitter, enabling a beacon signal every minute. The NanoBeacon’s low-power design, which features fast start-up and data transmission using only microwatts of power, supports Powercast in achieving this performance.
As the NanoBeacon moves farther from Powercast’s RF transmitter, beacon signals become less frequent, while moving it closer allows more frequency if the application requires it. The new distance achievement, say the company, is also due to its new reference design for its PCC110 Powerharvester chip and companion PCC210 boost converter, which join forces to harvest RF out of the air with up to 75 percent efficiency.
“Powercast’s and InPlay’s technologies combine to make every microwatt of power count in efficient and green IoT networks powered over the air, now at unprecedented distances, without batteries,” says Charles Goetz, CEO of Powercast. “Together we are advancing the IoT, creating the opportunity for new battery-free sensor types, low-power intelligent endpoints, and smart tracking tags used in retail, asset tracking and industrial sensing.”
InPlay’s NanoBeacon SoC family is designed to make smart sensor systems using active RFID technology affordable and easy to deploy, via Bluetooth Low Energy (BLE). It’s easily configured via an app, requires no software programming, transmits data up to 300 feet, and features software-defined radio (SDR) edge networking to connect tens of thousands of IoT devices.
“Maintaining billions of battery-powered IoT devices in the field is an expensive challenge,” says Jason Wu, co-founder and CEO of InPlay, “but with Powercast’s technology, our customers can design battery-free wireless sensors to avoid downtime and maintenance issues. Our technology is already easy and affordable to deploy vs. traditional RFID deployments which normally require technical experts. Now customers can also eliminate battery maintenance, and monitor more asset conditions when adding sensors to the system.”
