Cadence design flows and IP for Intel 16 FinFET process

Cadence design flows and IP for Intel 16 FinFET process

Technology News |
By Jean-Pierre Joosting



Cadence Design Systems has announced its digital and custom/analog flows are certified on the Intel 16 FinFET process technology and its design IP supports this node from Intel Foundry Services (IFS). The companies also delivered the corresponding process design kits (PDKs) to accelerate the development of a wide variety of low-power consumer, high-performance computing (HPC) and secure U.S. Military, Aerospace and Government (USMAG) applications. Customers can begin using the production-ready Cadence® design flows and design IP now to achieve design goals and speed time to market.

Intel 16 digital full-flow

The complete Cadence RTL-to-GDS flow has been certified and optimized for use with Intel 16 technology, allowing customers to meet power, performance and area (PPA) targets. The flow includes the Innovus™ Implementation System, Genus™ Synthesis Solution, Quantus™ Extraction Solution, Tempus™ Timing Signoff Solution and Tempus ECO Option, Pegasus™ Verification System and Pegasus DFM and Voltus™ IC Power Integrity Solution. Some of the Cadence flow’s capabilities for Intel 16 process rules have been enhanced, including via insertion and antenna rule support, which ensure high-quality designs.

Intel 16 custom/analog flow

Cadence Virtuoso® Studio, which consists of the Virtuoso Schematic Editor, Virtuoso Layout Suite, Virtuoso ADE Suite, and the integrated Spectre® X Simulator, have all been certified for Intel 16 technology. These tools have all been enhanced for better management of corner simulations, statistical analyses, design centering and circuit optimization.

The Virtuoso design platform provides a tight integration with the Innovus Implementation System, enhancing the implementation methodology of mixed-signal designs using a common database. In addition, the Virtuoso Layout Suite has been refreshed for efficient layout implementation on Intel 16, which leverages better performance and scalability throughout the layout environment; a non-uniform grid-based device place-and-route methodology with interactive, assisted features for placement, routing, fill and dummy insertion; width-based spacing pattern (WSP) support; integrated parasitic extraction and EM-IR checks; and integrated signoff-quality physical verification capabilities using Virtuoso InDesign DRC.

Intel 16 design IP

Cadence Design IP has been ported and silicon-tested for Intel 16 technology and including the enterprise-class PCI Express® (PCIe®) 5.0 and 25G-KR Ethernet multi-protocol PHY; multi-protocol PHY for consumer applications supporting standards such as PCIe 3.0 and USB 3.2; multi-standard PHY for LPDDR5/4/4X to enable a diverse set of memory applications; MIPI® D-PHY℠ v1.2, enabling a broad range of MIPI consumer applications such as cameras and displays; and MIPI SoundWire® I/O for audio applications.

“Our mutual customers create designs for a wide range of vertical markets, and in particular, the USMAG market has really come to rely on us as their trusted foundry partner due to their unique security requirements,” said Rahul Goyal, vice president & general manager for Intel’s Product & Design Ecosystem Enablement group. “Through our ongoing collaboration with Cadence, we’re empowering customers in all markets to unlock the power-saving benefits that come with our Intel 16 technology and the advanced Cadence flows and IP.”

“The Cadence R&D team collaborated with IFS to certify its flows and design IP for the Intel 16 process technology, ensuring customers have a fast path to adopt our technologies to deliver innovative consumer and USMAG applications in a timely manner,” said Nimish Modi, senior vice president and general manager, Strategy and New Ventures at Cadence. “With chip design innovation continuing to evolve at such a rapid pace, our customers can design with confidence, knowing that we’ve optimized our tools and IP so they can meet the most challenging design requirements.”

www.cadence.com
