Fast Wi-Fi HaLow SoC enables longest reach
Morse Micro has launched its highly anticipated second-generation MM8108 System-on-Chip (SoC), which builds on the success of the first-generation MM6108 SoC, while offering even better performance in all key areas of range, throughput, and power efficiency. It also reducing the cost, effort, and time to bring the next generation of Wi-Fi HaLow enabled products to market.
Enabling improved spectrum efficiency to minimize interference in high-density environments, the MM8108 delivers class-leading data rates of up to 43.33 Mbps using world-first sub-GHz 256-QAM modulation at an 8 MHz bandwidth, making it ideal for a range of applications in agricultural, mining, industrial, home, and city environments. Its integrated 26 dBm power amplifier with high efficiency, and low-noise amplifier (LNA) ensure exceptional performance and enable global regulatory certification without the need for external Surface Acoustic Wave (SAW) filters. The exceptional power efficiency significantly extends battery life and enables the uptake of solar-powered Wi-Fi HaLow connected cameras and IoT devices.
The MM8108 Wi-Fi HaLow SoC offers enhanced security that supports next-generation WPA3 with Simultaneous Authentication of Equals (SAE) and GCMP encryption for robust link-layer protection. Also, USB, SDIO and SPI host integration enables USB AP and STA dongle operation on new and existing network infrastructure. The compact 5- x 5-mm BGA package minimizes PCB size and cost.
The MM8108 is optimized for battery-operated applications with significantly extended sleep times and ultra-low power consumption in sleep modes. With class-leading Rx and Tx performance, it provides the fastest, longest reach Wi-Fi HaLow chip on the market, enabling countless applications including AI-enabled IoT devices and streaming of multiple 4K cameras in real-time over an extensive range.
“Once again, our engineering team has focused on creating the smallest, fastest and lowest power Wi-Fi HaLow chip in the market. The MM8108 enables powerful and practical solutions for the evolving demands of IoT. With features like host offloading, integrated amplifiers, and industry-leading security, the MM8108 makes developing long-range, low-power IoT applications more simple and cost-effective than ever before,” said Andrew Terry, co-founder and CTO of Morse Micro.
Complementing the cutting-edge MM8108, Morse Micro is also unveiling the MM8108-RD09 USB dongle reference design, which demonstrates the ease of upgrading new and existing Wi-Fi 4/5/6/6E/7 network infrastructure to support Wi-Fi HaLow. The dongle reference design will be made available to customers as a fully compliant Wi-Fi HaLow reference design, which can be used to build commercial USB dongles or to simplify the integration of the MM8108 silicon in end products.
Key features of the reference design include: include:
- A USB dongle incorporating the latest generation MM8108 Morse Micro chipset
- An SMA antenna selected for optimal performance
- A robust design that can be incorporated as-is into customers’ product designs
- Full compliance with the IEEE 802.11ah specifications
- Ready for Wi-Fi HaLow certification by the Wi-Fi Alliance
The MM8108-RD09 USB dongle will be bundled with Raspberry Pi 4B, power supply and antenna, and made available as a complete Wi-Fi HaLow evaluation kit (the MM8108-EKH19) targeting customers interested in testing and integrating the MM8108 within their platforms. This strong combination puts the MM8108 at the center of a ready-to-deploy, compact solution that robustly integrates Wi-Fi HaLow connectivity into existing devices with exceptional ease and efficiency.
“The MM8108-EKH19 is more than just a Wi-Fi HaLow evaluation platform – it’s an enabler of market transformation,” said Michael De Nil, co-founder and CEO of Morse Micro. “By simplifying the integration process, we’re making it easier for customers to adopt Wi-Fi HaLow, driving growth and opening doors to new opportunities in IoT and beyond. These solutions position Morse Micro as a leader in a rapidly expanding market, empowering businesses to leverage the full potential of Wi-Fi HaLow for transformative connectivity.”
The MM8108 SoC, MM8108-RD09 and MM8108-EKH19 are available for sampling and evaluation
