First low pin count MCUs with I3C support
Leading the way in I3C integration, Microchip Technology has released its PIC18-Q20 family, the industry’s first low pin count MCUs with up to two I3C peripherals and Multi-Voltage I/O (MVIO).
Available in 14- and 20- pin packages as small as 3 x 3 mm, the PIC18-Q20 MCUs are a compact option for real-time control, touch sensing and connectivity applications. The MCUs offer configurable peripherals, advanced communication interfaces and easy connection across multiple voltage domains without external components.
With the step-function increase in data collected and transmitted from cloud-connected edge nodes, Improved Inter Integrated Circuit® (I3C®) is rapidly becoming a more sustainable option for interfacing sensors with a high data rate and will help expand capabilities in next-generation devices.
With I3C functionality, flexible peripherals and the ability to operate on three independent voltage domains, PIC18-Q20 MCUs are well suited to be used in conjunction with a primary MCU in a larger overall system. This family of MCUs can perform tasks such as processing sensor data, handling low latency interrupts and system status reporting that the main MCU cannot perform as efficiently. While the CPU runs at a different voltage domain, the I3C peripheral operates from 1.0 to 3.6 V. These low-power, small form factor MCUs can be used in a wide range of space-sensitive applications and markets including automotive, industrial control, computing, consumer, IoT and medical.
“One of the main barriers to large-scale IoT adoption is the cost of implementing an edge node. With the PIC18-Q20 family, Microchip is helping to break down that barrier,” said Greg Robinson, corporate vice president of Microchip’s 8-bit MCU business unit. “By introducing the industry’s first low pin count MCU with I3C we are enabling flexible, cost-effective scaling of IoT applications and embracing the new standard communications interface.”
As the market shifts to demand higher performance with lower power and smaller size, I3C helps designers and software developers address these potentially challenging requirements.
Compared to I2C, I3C offers higher communication rates and lower power consumption, all while maintaining backward compatibility with legacy systems. The I3C and MVIO functionality, combined with Microchip’s configurable Core Independent Peripherals (CIPs), allow for lower system costs, reduced design complexity and a reduction in board space by replacing external level shifters with on-chip multiple voltage domains.
PIC18-Q20 MCUs are supported by a full development ecosystem of hardware and software tools, including the MPLAB® X and MPLAB Xpress Integrated Development Environments (IDEs) and MPLAB Code Configurator (MCC). Microchip’s development environment is straightforward and makes it easier to implement and generate code, allowing for a reduction in overall development time and reduced financial investment.
Developers can get a quick start in evaluating I3C and MVIO capabilities on the PIC18-Q20 using Microchip’s PIC18F16Q20 Curiosity Nano Evaluation Kit—a compact, cost-effective development board for rapid prototyping.
