HDMI 2.0 compliance test software for transmitters and receivers

HDMI 2.0 compliance test software for transmitters and receivers

New Products |
By eeNews Europe



The transmitter compliance test software allows engineers to use Agilent Infiniium oscilloscopes to test their HDMI 2.0 transmitters. The receiver compliance software can be used with the company’s transition-minimized differential-signaling signal generator platform and the M8190A arbitrary waveform generator to test HDMI 2.0 receivers.

Leading manufacturers are implementing HDMI technology in consumer products such as televisions, computers and set-top boxes, which requires them to pay close attention to device interoperability. The HDMI 2.0 specification, published Sept. 4, 2013, offers a significant increase in bandwidth (up to 18 Gbps) to support new features, better resolution and up to 32 audio channels.

Agilent’s HDMI 2.0 transmitter compliance solution builds on its HDMI 1.4b transmitter compliance test software that is currently used worldwide in HDMI authorized test centers. The software offers sophisticated capabilities now required for testing HDMI 2.0 transmitters, such as embedding standard cable models, de-embedding fixtures, providing reference equalization and allowing engineers to characterize their systems using arbitrary models.

The HDMI 2.0 transmitter compliance test software sets new benchmarks in usability by decreasing the number of “clicks to test.” Productivity improvements are enabled by two new software features: the ability to store and recall previous user set-ups, and test-plan control to guide users through all necessary tests for a given device, a capability previously lacking in HDMI solutions. Further increases in productivity are realized using a microwave switch matrix that allows all high-speed signals to be tested under control of the test software.

The HDMI 2.0 receiver compliance solution is available as an upgrade for Agilent E4887A TMDS signal generators and the M8190A AWG. A new cable emulator allows existing E4887A customers to upgrade to the HDMI 2.0 receiver test solution.

The M8190A AWG offers a cost-effective and compact alternative to Agilent’s well-established E4887A HDMI platform. The M8190A AWG setup eliminates switching between various cable emulators because waveforms are digitally synthesized to emulate the desired distortions. This capability reduces the manual reconfiguration effort and increases reliability. The AWG test solution reduces development costs while providing accurate test results with greater flexibility than other HDMI test solutions offer.

The HDMI 2.0 receiver compliance solution is complemented by products from Agilent’s solutions partner BitifEye. BitifEye products include an HDMI 2.0 upgrade of the frame generator software, phase shifters and an HDMI status and control data channel controller kit, which can be used to enable the new scrambling feature.

www.agilent.com
