High-power MEMS switch targets smart power, energy distribution

High-power MEMS switch targets smart power, energy distribution

New Products |
By Rich Pell

RF MEMS switch specialist Menlo Micro has introduced a SPST micromechanical power switch capable of handling 10A in a miniature 5 x 5-mm surface-mount package. With an ultra-low 0.010 ohm contact resistance, the MM9200 is offered as the lowest-loss and highest power capable micro-mechanical switch ever created.

The MM9200 targets a wide range of applications including industrial automation, smart building controls, advanced energy management systems, and many other space-constrained power distribution applications. The device’s scalable design and process technology, says the company, allow designers to reimagine power distribution from micro-grid to smart circuit breakers all the way to smart point of load switching, enabling total management and control with a virtually loss-less solution.

The device exhibits extreme mechanical endurance typically in the billions of switching cycles, which provides 1,000x better lifetime than traditional electromechanical relays. This reliability, and its arc-free capability can reduce unplanned maintenance and replacement costs while bringing safety innovations not previously possible for industrial automation applications.

In addition, says the company, the device’s 10 µs actuation speed is more than 1,000x faster than its electromechanical equivalent, enabling entirely new concepts for power switching and protection.

“Menlo Micro continues to innovate with the industry’s highest power rated micro-mechanical power switch ever brought to market,” says Chris Giovanniello, co-founder and SVP of Marketing, Menlo Micro. “With the MM9200 we are breaking entirely new ground, integrating more than 400 individual switches to support kilowatts of power in a small surface-mount package. With this extreme miniaturization and power density, Menlo Micro will play a pivotal role in increasing the energy efficiency, functionality, and reliability of a wide array of smart power and energy distribution applications.”

Like all of the company’s “Ideal Switch” products, the MM9200 employs true metal-to-metal contacts which reduce losses and power dissipation by more than 90% when compared to solid-state devices. This design, combined with the Ideal Switch electrostatic drive, makes the MM9200 the most power efficient, and space efficient high-power switch in the market, says the company.

MM9200 product highlights include:

  • Low on-state resistance: 10 mΩ
  • Continuous carry current (AC or DC): +/- 10A
  • Voltage standoff (AC or DC): +/- 300V
  • Fast switching time: 10µs to open, 10µs to close
  • Mechanical endurance: 1 billion switching operations
  • QFN and low-profile 5 mm x 5 mm WL-CSP package options available

The company says that it has begun working with early-access customers in the evaluation of the MM9200. Evaluation boards and engineering samples for general sampling will be available in 1H 2023.
