Take the wheel of a new car today, and you’ll be greeted with the bright glow of screens filled with useful data: how fast you’re going, what’s playing on the radio, a playlist of your songs, a phone book of your contacts, a map highlighting your current route, the fuel efficiency of your vehicle, whether there’s another car in your blind spot. The digital world applies to cars, too, and it’s supporting a safer and more engaging experience on the road.

Figure 1: Future cars will boast even more displays. Automotive-grade ICs
that meet ASIL B criteria support functional safety of these vehicle displays.

Side Mirrors: Relics of the Past?

Much like television screens, the displays inside cars are getting bigger and sharper. Analysts project strong growth in the >8-inch display market, with 12.3-inch displays gaining more traction for fully digital instrument clusters. By 2023, a 37-inch in-vehicle screen could be a common sight. In the coming years, 4K and, down the road, 8K resolutions will be the norm. Future automotive displays will boast capabilities like local dimming, which improves the contrast ratio to make colors more crisp and vivid.

For instance, a black screen would be truly black, making an instrument cluster easier to read. There will also be more displays inside each car; in fact, we can already count up to 10 displays in a modern vehicle: the instrument cluster, the center information display (CID) (1-2), smart back mirror, side mirror replacement (2), heads-up display (HUD), rear seat mount on the head support (2), and rear seat mount on the roof.


Figure 2: In-vehicle displays are getting bigger and sharper,
especially as cars become smarter.

Highlighting the infusion of display technology in cars, analysis from IHS Markit points out that cameras and displays are increasingly being recognized as viable replacements for traditional side mirrors, providing benefits in fuel efficiency and safety. “Aerodynamic improvements and enhanced visibility are the primary reasons behind emerging mirror replacement applications, while designers will welcome newfound freedom after having explored novel exterior mirrors in concept vehicles for decades. Now that the regulatory environment is taking shape to support this concept, production applications will soon follow,” according to IHS Markit. The firm projects that by 2025, nearly half a million side-view camera display systems will replace side mirrors each year in new vehicles.

Since these automotive displays are providing safety-critical information via advanced driver assistance systems (ADAS), they must comply with functional safety standards. ISO 26262 is an international standard for functional safety of automotive electronic/electrical systems. A key part of the standard is the Automotive Safety Integrity Level (ASIL), which classifies the inherent safety risk in an automotive system. There are four ASIL levels, with ASIL D requiring the most safety-critical process and testing, based on severity (of injuries), exposure (probability), and controllability. Typical automotive systems requiring ASIL D compliance include windshield wipers, electric power steering, side-view cameras (mirror replacements), airbag deployment, braking, and engine management. Table 1 highlights common ASIL metrics for single-point fault (a fault that leads directly to a safety violation) and for latent-point fault (a multiple-point fault that is not detected by a safety mechanism nor the user).

Table 1: ASIL metrics

Achieving ASIL B Compliance

Automotive displays, such as the instrument cluster display and the side mirror replacement display, typically require ASIL B compliance. Within the instrument cluster display are various blocks that should meet functional safety standards. Let’s take a look at how two of them, thin film transistor (TFT) bias for power management and the light-emitting diode (LED) backlighting driver, can be designed for ASIL B compliance. TFT bias typically consists of these voltages: AVDD and NAVDD for the TFT source driver, VGON and VGOFF for the TFT gate driver and, in some cases, VCOM for the liquid-crystal display (LCD) backplane. I2C and a fault pin are used to communicate with the host microcontroller unit (MCU). See Figure 3 for a diagram of a typical TFT bias application.


Figure 3: TFT bias application diagram

To achieve ASIL B compliance, the TFT bias block should ideally have these features, as shown in Figure 4:

  • I2C (the data signal and the clock signal) and the fault pin to perform setting adjustments and diagnostics on each rail
  • Undervoltage and overvoltage on each rail
  • Internal resistors with fixed or adjustable voltage through I2C (external resistors mean more points of failure, so designers typically avoid them)
  • Redundant reference
  • Open enable, which provides additional redundancy. When the enable is open, then the chip will look at another pin to determine whether it is on or off.


Figure 4: TFT bias ASIL B features

There are various TFT bias fault scenarios to be aware of:

  • VCOM voltage goes out of range
  • VGON voltage is in an overvoltage situation
  • Fail-safe operation with open enable pin

In the first two scenarios involving VCOM and VGON voltages, the fault pin will alert the MCU of the scenario. The MCU will then read the register to validate the situation and use I2C to adjust the voltages accordingly. In the last scenario, when the enable pin is open while FEN is still high, the output voltages will fall back to the default settings. The MCU can adjust the voltage via I2C.

Now, let’s turn our attention the LED backlighting driver. Figure 5 depicts a diagram of typical application circuitry for an LED driver. Here, the input is connected directly to the car battery, which has voltage protection when the output is short. The output can either be a boost or single-ended primary-inductor converter (SEPIC), depending on the number of LEDs per string. I2C and a fault pin are needed to communicate with the MCU.

Figure 5: LED driver typical application circuitry

To achieve ASIL B compliance, the LED driver would need to have these features, as shown in Figure 6:

  • I2C (the data signal and the clock signal) and fault pin to perform setting adjustments and diagnostics on each rail
  • Open or short LED per string detection
  • Output voltage measurement
  • LED current measurement per string
  • Internal resistors with fixed output or adjustable output through I2C
  • Open enable
  • Redundant reference to monitor the output

Figure 6: LED Driver ASIL B features

As with our TFT bias application, with LED drivers, there are also fault scenarios to address:

  • String 1 has LED open. In this case, the fault pin will alert the MCU to this condition, and the MCU will read the I2C register to know which LED string has an open. The MCU will then pump more current to the other strings to achieve the same brightness.
  • String 2 has LED short. As with the previous scenario, the fault pin will alert the MCU to the condition, and the MCU will read the I2C register to know which LED string has the short. To save power, the LED driver will shut down the string with the short. The MCU will then pump more current to the other strings to achieve the same brightness.
  • Boost output voltage is low. The fault pin again alerts the MCU, and the MCU reads the I2C register to know that the boost voltage is low. Usually, the out capacitor is short to ground, or the LED is short to ground. A front protection device such as PGATE will be open. In this scenario, only important messages like speed or engine temperature will be displayed on the dashboard.
  • Fail-safe operation with open enable pin. When the enable pin is open while FEN is still high, the LED driver current falls back to the default settings. The MCU can adjust the current via I2C.

Addressing the criteria outlined by the ASIL B standard, Maxim, an established leader in automotive-grade technologies, offers a portfolio of functionally safe display technologies. The company’s display bias ICs, LED drivers, power management ICs (PMICs), and other analog components are designed to support vehicle displays that enhance and ensure safety of drivers, passengers, and pedestrians. While many TFT bias ICs on the market don’t have a communication mechanism, Maxim’s ICs have I2C built in, along with the fault pin to communicate with the host MCU. Among the TFT bias products, for instance, is the MAX20067 TFT-LCD bias IC with VCOM buffer, level shifter, and I2C interface.

This PMIC provides the industry’s first integrated power solution for TFT-LCD with synchronous boost, gate shading, and I2C. Its I2C interface offers settings control as well as diagnostics and monitoring. It also has spread-spectrum modulation in the AVDD boost converters, which reduces peak interference and optimizes electromagnetic interference (EMI) performance. Among the backlighting products are the MAX20446 6-channel, I2C LED driver with high-voltage DC-DC controller and battery disconnect. Its integrated current-mode switching controller drives a DC-DC converter that provides the voltage needed for multiple strings of high brightness (HB) LEDs. I2C offers settings control as well as diagnostics and monitoring to support ASIL B requirements. Spread spectrum with phase shifting and hybrid dimming enhances EMI performance. The IC also offers very high dimming ratio for very bright sunlight as well as pitch-dark environments.


Needle-based speedometers, fuel gauges, and the like are quickly becoming things of the past as vehicle dashboards have gone digital. As the auto industry moves toward Level 5 fully autonomous vehicles, functional safety of key vehicle components, such as these digital displays, will be essential. For the underlying display technologies, functional safety is marked by compliance with the ASIL B standard. Automotive-grade ICs that are designed to meet ASIL B criteria can help streamline the design cycle for reliable, high-performing display applications designed to support driver, passenger, and pedestrian safety.

About the author: Szukang Hsien is Executive Business Manager, Automotive Business Unit, Maxim Integrated.
