Innovation measures luminous efficacy of LEDs more accurately

Innovation measures luminous efficacy of LEDs more accurately

Technology News |
Researchers at Aalto University and VTT Technical Research Centre of Finland have succeeded in developing a method which helps to improve the relative uncertainty in measuring the luminous efficacy of LEDs from the approximate five percent of today to one per cent in the future.
By eeNews Europe

Share:

Solutions based on incandescent lamps have so far been used in photometry, i.e. in measuring light detected by the human eye, pointed out Tomi Pulli, a doctoral student at Aalto University.

The photometers that lamp manufacturers use for calibrating their devices have been produced and calibrated for incandescent lamps, which results in errors when measuring the efficacy of LEDs. In our research, we used a LED lamp with a well-defined spectrum and a PQED detector, which we developed together with VTT MIKES Metrology and European partners, and whose spectral responsivity can be determined highly accurately. Therefore, there was no need for the problematic optical filters used in applications based on incandescent lamps. Accoring to Pulli accurately determining and analysing the spectrum of the LED was the most challenging and crucial part of the research.

The detector used in measurements by Pulli and his co-researchers measures the illuminance of LEDs in a small area. According to Professor Erkki Ikonen, the head of research, the next step will be to move onto measurements corresponding to real-life conditions for lighting.

LED lamps emit light to all directions. In order to measure the luminous efficacy a device called an integrated sphere is used which takes into account light coming from different directions.  There is still little information available on their actual efficacy and ageing properties. Indeed, it is essential to determine luminous efficacy as accurately as possible so that such lamps can be introduced in the market that transform as much electrical energy into light useful to the human eye as possible.

So far, the portion of LEDs has been around ten per cent globally, but the amount is increasing at a rapid pace, suggested Ikonen.

Lighting amounts to approximately 20 per cent of the electricity consumption in the world. Once the share of LEDs increases close to 50 per cent, an improvement of as little as one percent in the accuracy of measuring the luminous efficacy of the lamps introduced in the market will mean saving billions of euros each year.


Reference
Light: Science & Applications (2015) 4, e332; doi:10.1038/lsa.2015.105
Published online 11 September 2015
