Low-profile ring-type 2-phase incremental encoder with hollow shaft
The necessary detent torque amounts to 18±7mNm. Rated for voltages of 5VDC, the EC35A has a maximum operating current of 10mA. The operating temperature ranges from –40°C to +85°C. The combination of an encoder with large hollow shaft and the reduced shaft wobble provide a comfortable operation and an accurate operation feeling.
In particular the encoder’s hollow shaft contributes to more freedom of set design as devices such as switches and LEDs can be mounted into its center. Typical applications of the EC35A are among others volume control and function change for car AV equipment and navigation systems, temperature control for HVACs, menu selection for home appliances such as washing machines and microwave ovens.
