Lowest drift claimed for bandgap voltage reference
The company claims this is the industry’s lowest drift bandgap voltage reference.
It outputs 2.5V from inputs between 50mV above the output, up to 40V, and with a supply current of 1.2mA. In shutdown mode, power consumption is reduced to 4-microamps. Load regulation error is less than 6ppm/mA and line regulation error is less than 4ppm/V, both under worst-case conditions. The LT6657 is fully specified for –40°C to 125°C and was designed for applications in instrumentation, test equipment and automotive systems. Additional voltage options are in development. Prices start at $3.19 each in 1,000-piece quantities.
Summary of Features:
A-Grade (0.1% Initial Accuracy, 1.5ppm/°C Drift)
B-Grade (0.1% Initial Accuracy, 3ppm/°C Drift)
0.5ppmP-P Noise (0.1Hz to 10Hz)
Fully Specified Over –40°C to 125°C
±10mA Sink & Source Capability
Low Power Shutdown: <4µA Maximum
Operates on a Supply Voltage up to 40V
Guaranteed Low Dropout Voltage:
50mV @ No Load
–150mV @ –10mA Load Current
450mV @ 10mA Load Current
Guaranteed Load Regulation:
3ppm/mA Maximum @ 25°C
6ppm/mA Maximum Over Temperature
Guaranteed Line Regulation:
2ppm/V Maximum @ 25°C
4ppm /V Maximum Over Temperature
2.5V Voltage Option Available Now
Additional Options in Development Contact Marketing
8-Lead MSOP Package
For more information, visit www.linear.com/product/LT6657
