MEMS scanner for eyeglasses and head-up displays

MEMS scanner for eyeglasses and head-up displays

Technology News |
By Jean-Pierre Joosting



The latest MEMS scanner from Infineon Technologies AG, comprising a MEMS mirror and MEMS driver, allows completely new product designs for eyeglasses and head-up displays. Its miniature size and low power consumption are the basis for making augmented reality (AR) more widely available for consumer applications such as wearables and for automotive head-up displays.

“Augmented reality solutions enrich real environments with valuable digital data and help people to move around more conveniently and safely in daily life, for business and leisure activities, but especially on the street,” said Charles Chan, head of Infineon’s automotive MEMS product line. “Maps, infotainment or messages projected on everyday glasses guide people to the nearest supermarket or shared car park around the corner. Overlaying valuable information, from route navigation to driver assistance systems, over the car’s complete windshield, instead of just over a small area in front of the driver, is a major step ahead for improving driving safety and convenience.”

Infineon’s MEMS scanner chipset features an innovative tilting mirror which lays the foundation for a new generation of laser beam scanner (LBS) projectors. Compared to alternative system designs and competitive MEMS scanner systems, Infineon’s new chipset stands out in terms of performance, size, energy consumption and competitive system costs.


A major challenge when developing AR-HUDs is integrating the system into the dashboard, due to space restrictions. Conventional HUD systems can be more than 30 liters in optical volume, yet still offer only a very modest field of view. By contrast, laser beam scanners based on Infineon’s MEMS scanner chipsets enable HUD systems with minimum optical volume, so they can be integrated into even the smallest dashboard. Easy integration together with a competitive bill of material also bring AR-HUDs with a large field of view to small cars and compact classes.

The Infineon MEMS scanner chipset enables the design of an AR micro-projector which is light in weight and can be aesthetically integrated into all-day-wear eyeglasses and sports glasses. Thanks to the chipset’s low power consumption, small batteries can easily be integrated into the frame, allowing the glasses to be worn conveniently throughout the day without the need to frequently recharge the batteries.

To advance the development of AR smart glasses’ systems for the consumer market, Infineon is collaborating with TriLite Technologies GmbH, a Vienna-based start-up. While Infineon looks after the MEMS scanner chipset, TriLite is responsible for system integration and control algorithms that enhance the optical performance of the system. Both companies combine several years of research in optical MEMS and mass manufacturing capabilities.

www.infineon.com
www.trilite-tech.com
