Based on its invention of a new type of quasi-particle called a hybrid plasmon polariton, Berkeley Lab’s HPP sidesteps optical losses plaguing earlier attempts at silicon photonics with a new operating mode that makes the best of photonic and plasmonic systems—combining high quantum confinement with low signal loss, thus opening the door to the nanoscale on-chip lasers, quantum computing, and single-photon all-optical switches.

Created in the lab of Xiang Zhang, principal investigator with Berkeley Lab’s Materials Sciences Division and director of the University of California at Berkeley’s Nano-scale Science and Engineering Center, the breakthrough was also facilitated by doctoral candidates Volker Sorger and Ziliang Ye, who claim that HPPs will enable a new era of nanoscale waveguides for intra-chip optical communication, signal modulation, on-chip lasers and bio-medical sensing.

Quasi-particles called surface plasmon polaritons (SPPs) were already known to be created by directing waves of light across a metal surface to generate electronic surface waves—called plasmons—that then interact with photons. Unfortunately, SPPs suffer significant signal losses when propagating through metal. The Berkeley Lab researchers solved this problem by adding a low-k dielectric layer between the metal and the semiconductor to form a metal-oxide-semiconductor architecture that redistributes incoming light waves into the low dielectric gap where optical losses are less.

3-D image overlap of the deep sub-wavelength HPP mode signal (red spot) that indicates the waveguide’s potential to create strong light-matter-interaction for compact and highly functional photonic components. (Photo courtesy of Zhang group).

The resulting HPPs propagate more freely, providing designers with a best-of-both-world’s scenario where nanoscale waveguides can be cast on standard CMOS chips with optical properties rivaling exotic III-V compounds. The researchers estimate that it will take two to five years to commercialize the technique.

Funding for the project was provided by the National Science Foundation’s Nano-Scale Science and Engineering Center.
