Quantum tunnelling boosts compact terahertz source power
Researchers in Austria have used quantum tunneling to develop a compact terahertz source with ten times the power to current devices.
Terahertz radiation has a wavelength of typically a little less than one millimetre and producing this is a challenge and is needed in many areas, from material testing or airport security control to radio astronomy, as well as 6G future telecommunication systems.
The team at the Technical University of Vienna (TU Wien) developed an extremely simple and compact source of terahertz radiation using an oscillator with double resonant-tunnelling (RTDs) diodes built from InGaAs/AlAs grown on an InP substrate using standard lithography. The radiation power significantly outperforms similar devices with power of 10 μW at the fundamental frequency of 525 GHz and 70 μW at 330 GHz.
“Today, there are various ways to generate terahertz waves,” said Prof Michael Feiginov of the Institute of Electrodynamics, Microwave and Circuit Engineering at TU Wien. “One can use quantum cascade lasers, for example. With those, it is possible to achieve high intensities, but they have to be cooled down to very low temperatures. Also, large, complicated photonic systems can be used, with several optical lasers whose radiation is mixed together to produce longer wavelengths. This makes it possible to produce the desired wavelengths in a very flexible way.”
“However, our goal was to develop a simple and extremely compact terahertz source,” he said. “If we want a technology to be incorporated into everyday devices in the future, then the terahertz sources must be small and function at normal room temperature.”
To do this, the team now used neither optical nor quantum cascade lasers, but simple oscillators. “Oscillators are something quite common in electrical engineering,” said Petr Ouředník, researcher at TU Wien. If certain electronic components, such as coils and capacitors, are coupled, then the energy flows back and forth between them, thereby generating electromagnetic radiation.
“But the problem is usually the losses, which you can imagine as electric resistance,” said Ouředník. “This normally ensures that the oscillations in these resonant circuits come to a standstill after a very short time.”
However, this can be changed by tapping into the quantum properties of the devices.
“We use resonant-tunnelling diodes, where the current flows between two barriers as a result of tunnelling,” said Ouředník. “The quantum well between the barriers is particularly narrow in our structures, so only very specific and very few electron states can exist there.” By applying a voltage, these electron states and their energies can be changed.
Normally, the current flow increases when the electrical voltage is increased – the electrical resistance indicates to what extent. In resonant-tunnelling diodes, however, the opposite effect is possible: if the voltage increases, it can happen that the electron states in the quantum well no longer match the electron states in the other parts of the structure. This means that the electrons can no longer cross over from one area to the other, and the current flow decreases instead of increasing. This means the electrical resistance becomes negative. “A negative resistance in the oscillating circuit, however, means that the oscillating circuit does not lose its energy, it gains energy instead. The electromagnetic oscillations keep going by themselves and the external direct current is converted into terahertz radiation,” said Feiginov.
This provides high intensity of the terahertz radiation in a structure is smaller than a millimetre and built only with current optical lithography. It would therefore be potentially suitable to be built into compact devices such as smartphones.
“There are so many application ideas that we can’t even say today which one is the most realistic,” says Feiginov. “The terahertz range is used in radio astronomy, one can use it to see through optically opaque objects, for example in security checks at the airport or even in material testing. Another exciting application are chemical sensors: different molecules can be recognised by the fact that they absorb very specific frequencies in the terahertz range. All these technologies will benefit from simple and compact terahertz sources, and that’s what we wanted to make an important contribution to.”
DOI: 10.1063/5.0068114; www.tuwien.ac.at
