Self-powered tactile sensors for robotics and wearables
Researchers in South Korea have found ways to improve the manufacturing and performance of self-powered tactile sensors for robotics and wearable devices.
The team at Chung-Ang University in South Korea looked at both piezoelectric and triboelectric tactile sensors which generate their own power.
Piezoelectric and triboelectric (TENG) tactile sensors are designed to convert mechanical stimuli into electrical signals, making them critical components in intelligent systems. Piezoelectric sensors leverage voltage generation through mechanical stress in non-centrosymmetric materials, such as quartz and polyvinylidene fluoride (PVDF), while triboelectric sensors operate on contact-induced charge transfer. Both sensor types offer unique advantages, including self-powered functionality and high sensitivity but also face challenges, such as material brittleness and environmental limitations.
The march of the humanoid robots
The team of researchers led by Professor Hanjun Ryu introduced novel manufacturing strategies to overcome these limitations. The findings show that a combination of innovative material engineering and advanced fabrication techniques is essential for creating sensors capable of multi-modal sensing and real-time interaction.
For piezoelectric sensors, the researchers highlighted the importance of increasing the piezoelectric constant through methods, such as doping, crystallinity control, and composite material integration. Notable advancements include using lead-free ceramics and polymer blends to create flexible, environmentally friendly sensors suitable for dynamic applications. The integration of 3D printing and solvent-based crystallization techniques was also found to significantly improve the sensitivity and adaptability of these sensors.
The triboelectric sensors were enhanced through surface modification techniques, such as plasma treatments, microstructuring, and dielectric constant optimization. These strategies increased charge transfer efficiency and enabled the development of durable, high-output sensors. The researchers also demonstrated the effectiveness of hybrid materials and nanostructures in boosting triboelectric performance while maintaining flexibility and environmental resilience.
“Our study explains the materials and device fabrication strategies for tactile sensors using piezoelectric and triboelectric effects, as well as the types of sensory recognition,” said Prof. Ryu. “These strategies aimed to enable the development of high-performance sensors for applications in robotics, wearable devices, and healthcare systems.”
The study also underscores the potential for integrating AI with tactile sensors for advanced data processing and multi-stimuli detection. Using AI-driven analysis of tactile inputs, such as texture and pressure recognition, can significantly enhance the accuracy and functionality of these devices. These integrations pave the way for next-generation sensors that mimic human sensory capabilities while achieving higher operational efficiency.
“It is anticipated that AI-based multi-sensory sensors will make innovative contributions to such advancements in various fields,” said Ryu.
