TI switching regulator offers industry’s lowest quiescent current
The TPS62840 synchronous step-down converter has an operating quiescent current of 60 nA and delivers a light-load efficiency of 80% at 1-µA load. As a result, says the company, it enables designers to extend the battery life of their systems, or use fewer or smaller batteries to shrink their overall power supply solution size and reduce cost.
In addition, the device’s input voltage (VIN) range of 1.8 V to 6.5 V supports a variety of battery chemistries and configurations. These features plus its selectable functions, says the company, make it ideal for many battery-powered, always-on industrial and personal electronics applications – including narrow-band Internet of Things (IoT), grid infrastructure equipment, and wearables – that require more flexibility, an extended wireless range, improved accuracy and reduced electromagnetic interference (EMI).
Key features and benefits of the TPS62840 are offered as the following:
- Longer battery life, very high light-load efficiency: A lower IQ draw delivers longer battery life for systems with very light loads (less than 100µA), and those operating primarily in standby/ship mode (not switching). The low IQ of the TPS62840 enables its 80% efficiency at a 1-µA load, which is up to 30% better than competitive devices.
- Selectable modes enhance performance, lower overall cost: The TPS62840’s selectable mode and stop functions improve noise performance and reduce signal distortion. These benefits can help lower the solution cost because designers can achieve system requirements without using more expensive precision signal-chain components, sensors or radio solutions to perform the same functions.
- The mode pin allows for continuous conduction mode, also called forced pulse-width modulation mode, to improve ripple or noise performance and lessen the impact on transmissions in sensitive radio-frequency applications.
- The stop pin turns off all switching to reduce EMI or ripple, and minimizes distortions passed to precision signal-chain, measurement, sensors or wireless connectivity components.
- Smaller solution size: Engineers can use the new switching regulator to cut their battery count in half or use smaller batteries in their design. For example, designers can save up to 16,980 mm3 using four AAAs instead of four AAs.
- Flexible VIN broadens applications: The TPS62840’s wide range of 1.8 VIN-6.5 VIN accommodates multiple battery chemistries and configurations, such as two lithium manganese dioxide (2s-LiMnO2) cells in series, single-cell lithium thionyl chloride (1xLiSOCL2), four-cell and two-cell alkaline, and lithium polymer (Li-Po).
Pre-production samples of the TPS62840 are available through the TI store in the following packages: eight-pin small outline no-lead (SON), measuring 1.5 mm by 2.0 mm; six-pin wafer chip scale package (WCSP), measuring 0.97 mm by 1.47 mm. An eight-pin thermally enhanced package (HVSSOP), measuring 3 mm by 5 mm, will become available later this year.
Pricing starts at $0.85 in 1,000-unit quantities. The TPS62840-1DLCEVM55 and TPS62840-1YBGEVM56 evaluation modules are available for $49 each.
