Ultra-low power platform from TSMC targets IoT and wearable device applications
In this platform, the company offers multiple processes to provide significant power reduction benefits for IoT and wearable products and a comprehensive design ecosystem to accelerate time-to-market for customers.
TSMC’s ultra-low power process lineup expands from the existing 0.18-micron extremely low leakage (0.18eLL) and 90-nanometer ultra low leakage (90uLL) nodes, and 16-nanometer FinFET technology, to new offerings of 55-nanometer ultra-low power (55ULP), 40ULP and 28ULP, which support processing speeds of up to 1.2 GHz. The wide spectrum of ultra-low power processes from 0.18-micron to 16-nanometer FinFET is ideally suited for a variety of smart and power-efficient applications in the IoT and wearable device markets. Radio frequency and embedded Flash memory capabilities are also available in 0.18 µm to 40 nm ultra-low power technologies, enabling system level integration for smaller form factors as well as facilitating wireless connections among IoT products.
Compared with their previous low power generations, these ultra-low power processes can further reduce operating voltages by 20% to 30% to lower both active power and standby power consumption and enable significant increases in battery life — by 2X to 10X — when much smaller batteries are demanded in IoT/wearable applications.
One valuable advantage offered by the ultra-low power technology platform is that customers can leverage TSMC’s existing IP ecosystem through the Open Innovation Platform®. Designers can easily re-use IPs and libraries built on TSMC’s low-power processes for new ultra-low power designs to boost first-silicon success rates and to achieve fast time-to-market product introduction. Some early design engagements with customers using 55ULP, 40ULP and 28ULP nodes are scheduled in 2014 and risk productions are planned in 2015.
