What is the ideal rectifier for fast switching applications? Comparing Trench and Planar Schottky.

May 30, 2022

By Nexperia

 A new generation of Trench Schottky rectifiers combines low switching losses and leading thermal performance.

 This white paper will help you:

• Understand the differences between planar and Trench Schottky technology

• See how the safe operating area (SOA) advantage of Nexperia’s Trench Schottky rectifiers prove useful in applications where higher ambient temperatures have to be tolerated

• Discover the impact of the lower Qrr of Trench Schottky on the efficiency of a 48V/12V switch-mode converter
