Startup enables cryogenic chip design to scale quantum computers
Semiwise in Glasgow, UK, has developed IP and methodology for cryogenic process development kits (PDKs) that allow CMOS circuits optimised for quantum computers that operate at cryogenic temperatures to be manufactured by conventional foundries.
A quantum computer needs control electronics to manipulate and read out from the qubit array, and to store and process the resulting data. Current implementations typically involve a qubit array chip located in a cryostat, with multiple coaxial cables running to banks of high-precision room-temperature control electronics.
This represents a major barrier to scaling because it’s impractical to run thousands of cables into cryostats, and the long cables introduce delays in signal transmission.
In principle, this integration problem can be solved using conventional silicon CMOS fabrication technology bringing the controlling and data processing CMOS chips closer to the qubits in the cryostats. However, existing integrated circuit design methodologies are only validated at temperatures close to room temperature (typically in the range -40C to +125C), whereas qubit arrays operate at significantly lower temperatures.
At such low temperatures commercial process design kits (PDKs) enabling the chip design and verification are not available which currently renders the cryogenic chip design practically impossible. Simultaneously semiconductors exhibit significantly different electronic characteristics at cryogenic temperatures, and the conventional CMOS IP and chip design solutions may not work as intended.
Based on this technology the company will be offering services for standard foundry process design kits (PDKs) for allowing proper analogue and digital design at cryogenic temperatures. This will minimize the excess heat generated thereby easing the scalability challenges for large quantum computers.
Related articles
- SureCore expands into control logic for quantum computing
- Cryogenic CMOS IC operates at -270ºC, controls up to 128 qubits
- Intel taps Dutch team for second generation quantum controller
- Microsoft’s quantum cryogenic CMOS chip controls thousands of qubits
- CryoCoax signs technology partnership with Delft Circuits
- European startup ships first commercial quantum processor
“We are excited to become part of the QC revolution by providing for our customers with the much needed cryogenic PDKs and enabling cryogenic chip design and IP generation, enabling the QC scaling,” said Professor Asen Asenov, CEO of Semiwise.
Asenov was the founder of Gold Standard Simulations (GSS), a 2010 startup from the University of Glasgow which developed the first TCAD based Design-Technology Co Optimisation (DTCO) tool chain. After the acquisition of GSS by Synopsys in 2016 the TCAD-to-Spice technology originally developed by GSS is now part of the Synopsys TCAD offering in the so called TCAD-to-Spice flow
This technology will be used in the Cryogenic PDK re-centreing.
Semiwise develops innovative low-power CMOS transistor-level IP that improves performance and variability, and drastically reduces power consumption. SemiWise also offers simulation services and consulting to the semiconductor industry including fables, IEDM and foundry players.
Asenov is also a Director of Surecore in Sheffield which is using its low power SRAM technology to develop memories and microcontroller IP designs for cryogenic quantum computer applications.
