eFuse for 800V SiC EV designs
Asahi Kasei Microdevices (AKM) and Silicon Austria Labs (SAL) have completed a joint proof of concept of the eFuse technology in 800V silicon carbide (SiC) designs.
The eFuse board developed and tested with SAL is based around the AKM current sensor which can detect a current spike in under 100ns.
This shows that the eFuse technology can significantly improve safety, as well as reducing material and maintenance costs of systems such as on-board chargers (OBC) in automobiles says AKM.
The popularity of SiC- and gallium nitride (GaN)-based power devices in electric vehicles and other high-voltage applications is on the rise. This makes it necessary to replace mechanical fuses – which have been utilized with conventional silicon (Si) based power converters – in order to immediately shut down the system when detecting an overcurrent, protecting the devices and avoiding costly maintenance.
AKM is producing the CZ39 series, a coreless current sensor with a response time of 100 ns. Its fast response capability and high accuracy allow for precise detection of overcurrent and quick system shutdown.
In a joint technical verification together with SAL in Graz, AKM has developed the eFuse system which solves the challenges of conventional protection systems using mechanical fuses.
This provides the overcurrent and short circuit protection required for high-voltage EV systems with SiC- and GaN-based power devices, such as OBCs. Furthermore, the current sensor integrated into the eFuse can efficiently regulate the current in connected subsystems, thereby reducing the overall part count.
“With this joint technology validation, we have set a new standard for eFuse technology, and we are proud to combine AKM’s expertise with SAL’s research capabilities to achieve this innovative result. We expect that the eFuse technology will contribute to smaller and lighter EV onboard chargers,” said Toshinori Takatsuka, General Manager of AKM’s current sensor business.
“By utilizing the latest AKM current sensing technologies, we can improve the reaction time of eFuses and the protection of wide-bandgap power converters,” said Thomas Langbauer, Team Lead within the Power Electronics Division at SAL.
AKM is showing the results of the joint research with SAL at PCIM Europe 2024 in Nuremberg, Germany this week and are discussing further steps.
https://silicon-austria-labs.com/; www.asahi-kasei.com
